HT Silicon
Product Information
[HT Silicon] is under development silicon material, which improved less transmittance of 9um needs for human detection at far-infrared regions. Since this silicon material is low cost comparing with other materials for far-infrared transmitted materials such as Germanium, [HT silicon] is suitable material for low cost and mass production performance in lens of night vision camera of car or infrared camera.
Characterization
Significantly, around 9um range of transmittance is improved a lot comparing with normal single crystalized silicon for semiconductor (right hand side graph).
The manufacturing cost is the same as the one for semiconductors. So, applying this item for an optical purpose will make low cost and good performance in middle transmittance.
1. Product Information
- Crystal growth : CZ
- Diameter : 4, 5, 6, (8) inch
- Resistivity : ≥180 ohm-cm
- Oxygen Concentration : ≤8.0×10E15 atoms/cm3
- Polycrystal
Please ASK for customization.
2. Product shape
STC can provide the polished wafer (PW) product, as a lapped wafer (LW), like a sliced wafer, or even by ingot base.
3. Special customization
As per the customer's requests, STC applies to provide by lens or window material shape with Anti-reflective (AR) coating or Diamond-like carbon (DLC) coating.
